Photographs of the planets

Mercury

afbeelding
  • Date: 11 February 2003
  • Location: Brisbane, Australia
  • Telescope: Celestron C8 f/10 Schmidt-Cassegrain on a Vixen GP-DX mount
  • Camera: Vesta Pro modified CCD webcam, resolution 0.26 arcsec/pixel

Earth-based image of surface detail on Mercury. Parts of the imaged surface haven't been mapped by spacecrafts like Mariner 10. Explanation of the photographed surface.

afbeelding
  • Date: 25 January 2004
  • Location: Leyburn, Australia
  • Telescope: Celestron C9.25 235 mm SC at f/29 on a Vixen GP-DX mount
  • Camera: Vesta Pro modified CCD webcam, resolution 0.17 arcsec/pixel

The same part of the surface was also imaged one year later. Now with the C9.25 telescope.

afbeelding
  • Date: 25 January 2004
  • Location: Leyburn, Australia
  • Telescope: Celestron C9.25 235 mm SC at f/29 on a Vixen GP-DX mount
  • Camera: Vesta Pro modified CCD webcam, resolution 0.17 arcsec/pixel

The same photograph as above, but now in greyscale.

afbeelding
  • Date: 11 February 2003, 17/21/25 January 2004
  • Location: Brisbane/Leyburn, Australia
  • Telescope: Celestron C8/C9.25 on a Vixen GP-DX mount
  • Camera: Vesta Pro modified CCD webcam

The photographs that were made resulted in an animation of the rotation of Mercury and another confirmation of the imaging of the Kuiper-Murasaki ray system. Static version of the animtion.

Venus

afbeelding
  • Date: 4 October 2002
  • Location: Leyburn, Australia
  • Telescope: Celestron C8 f/30 on a Vixen GP-DX mount
  • Camera: Vesta Pro modified CCD webcam, 402x1/100s

afbeelding
  • Date: 8 June 2004
  • Location: The Netherlands
  • Telescope: unknown
  • Camera: unknown

Mars

afbeelding
  • Date: 4 September 2003
  • Location: Brisbane, Australia
  • Telescope: Celestron C8 203 mm SC at f/31
  • Camera: Vesta Pro modified CCD webcam, resolution 0.18 arcsec/pixel

Some markings on the C8 image can be associated with some geological landforms like Olympus Mons, parts of Valles Marineris, the craters Newton and Copernicus. Comparison with a photograph made by Hubble telescope.

afbeelding
  • Date: 12 October 2003
  • Location: Brisbane, Australia
  • Telescope: Celestron C8 203 mm SC at f/31
  • Camera: Vesta Pro modified CCD webcam, resolution 0.18 arcsec/pixel

Jupiter

afbeelding
  • Date: 3 April 2005
  • Location: Brisbane, Australia
  • Telescope: Celestron C9.25 235 mm SC at f/29
  • Camera: Vesta Pro modified CCD webcam, resolution 0.17 arcsec/pixel
afbeelding
  • Date: 15 March 2005
  • Location: Brisbane, Australia
  • Telescope: Celestron C9.25 235 mm SC at f/29
  • Camera: Vesta Pro modified CCD webcam, resolution 0.17 arcsec/pixel
afbeelding
  • Date: 28 February 2004
  • Location: Brisbane, Australia
  • Telescope: Celestron C9.25 235 mm SC at f/29
  • Camera: Vesta Pro modified CCD webcam, resolution 0.17 arcsec/pixel

Saturn

afbeelding
  • Date: 19 February 2005
  • Location: Brisbane, Australia
  • Telescope: Celestron C9.25 235 mm SC at f/29
  • Camera: Vesta Pro modified CCD webcam, resolution 0.17 arcsec/pixel
afbeelding
  • Date: 9 February 2004
  • Location: Brisbane, Australia
  • Telescope: Celestron C9.25 235 mm SC at f/29
  • Camera: Vesta Pro modified CCD webcam, resolution 0.17 arcsec/pixel

Uranus

afbeelding
  • Date: 29 July 2002
  • Location: Brisbane, Australia
  • Telescope: Celestron C8 f/30
  • Camera: Vesta Pro modified CCD webcam, 11867x1/10s

Neptune

afbeelding
  • Date: 31 July 2002
  • Location: Brisbane, Australia
  • Telescope: Celestron C8 f/30
  • Camera: Vesta Pro modified CCD webcam, 8888x1/10s
